Click Here for Kwikset Halo Select Install Instructions
Specifications
Power
6V, 4 x AA alkaline batteries, 6-months battery life
Lithium-ion battery life, 9-months battery life (Lithium-ion battery pack sold separately)
Door Prep
2 1⁄8" diameter cross bore hole &
1" diameter edge bore hole
Latch Backset
Adjustable 2 3⁄8" or 2 3⁄4"
Door Thickness
1 3⁄4" standard
Service part available for 2 3⁄4" thick doors.
Faceplates
1" x 2 1⁄4" round corner faceplate standard (For Kwikset)
Strikes
1 1⁄8" x 2 3⁄4" x round corner/square corner 4-hole strike
Bolt
1" throw, steel deadbolt
Door Handing
Reversible for right or left-hand doors
Cylinder
SmartKey Security™ KW1 cylinder
UL Rated
20 min UL fire rating
Security
Deadbolt: A156.40 Grade AAA Certified
Temperature Range
Exterior: -40F to 150F, Interior: 32F to 130F
Humidity
Exterior: 100% condensing, Interior: 30% to 95% non-condensing
Warranty
Lifetime Limited Mechanical and Finish Warranty. One Year Limited Electronics Warranty
