FOR DOORS: 1-3/4” to 2-1/4” thick (Preset for 1-3/4” door)
APPLICATION: Through door thru-bolting
DOOR PREP: Standard ANSI A156.115 (161) for Cylindrical Locks
BACKSET: 2-3/4” Standard..
CHASSIS: Heavy duty zinc diecast, investment cast, chromated cold rolled steel, stainless steel and EZAC™ diecast mechanism. Billet Steel spindles for locking functions.
FRONT: 2-1/4” x 1-1/8”
STRIKE: ASA standard
LATCHBOLT: 9/16” Throw Deadlocking
HAND: Non-handed
TRIM:
- Solid Zinc diecast PHL Levers
- 41 ° Lever Rotation Standard with 2-3/4” backset
- Wrought Brass Roses, Concealed Screws
KEYWAYS: SCC standard (Schlage C Compatible)
INTERCHANGEABLE CORE: Available prepped for IC cores compatible with Best, Falcon and Arrow or equivalent.
FINISH: 626 (US26D)
