HES 1500-630 Electric Strike Kit

SKU # HE/1500-630

The Master Lock No. 1500D Standard Dial Combination Padlock features a 1-7/8in (48mm) wide metal body for durability, with a stainless steel cover. The 9/32in (7mm) diameter shackle is 3/4in (19mm) long and made of hardened steel, offering extra resistance to cutting and sawing. The 3-digit combination offers keyless convenience. The locking mechanism features anti-shim technology, offering maximum security. The Limited Lifetime Warranty provides peace of mind from a brand you can trust.

"The Heavy Duty, Low Profile Solution for Latchbolts"

Specifications include:

  • Electric Strike Kit
  • Satin Stainless Steel
  • Stainless steel construction
  • Tamper resistant
  • Static strength 1500 lbs
  • Dynamic strength 70 ft-lbs
  • Endurance 1,000,000 cycles
  • Field selectable fail safe/fail secure
  • Dual voltage 12/ 24 VDC/VAC
  • Non-handed
  • Interchangeable faceplates and accessories
  • Field replaceable components
  • Fully finished faceplate, keeper, case and trim
  • Field adjustable integrated shim
  • ElectroLynxâ„¢ connectors

Delivery: The HES 1500-630 Electric Strike Kit is in stock, please allow 1-2 business weeks' lead time.

G.S.A. Contract Holder
This item is available on our
GSA contract # 47QSWA19D001W
US$330.00

Description:

Description:

HES 1500-630 Electric Strike Kit

1500 - Combination Padlock by Master Lock

The world's highest-selling combination lock is available at the best price online and ready to ship. Master Lock's 1500 series padlocks are the choice of schools and institutions across the country and the globe. The 3-digit combination mechanism has over 64,000 possible combinations, and the 7mm shackle fits all standard lockers.

The 1500 is a box pack with serial numbers provided. The 1500D comes as individually carded (Individual Blister Pack) and not available with serial numbers.

Features and Benefits:

- Stainless steel construction.
- Tamper resistant.
- Field selectable fail safe/fail secure.
- Static strength 1500 lbs. (fail secure).

- Dynamic strength 70 ft-lbs. (fail secure).
- Endurance 1,000,000 cycles.
- Fail secure (standard).
- Dual voltage 12VDC or 24VDC continuous duty.
- Non-handed.
- Field replaceable components.
- Fully finished faceplate, keeper, case and trim.
- Field adjustable integrated shim.
- ElectroLynx® connectors.
- Frame Application: Metal & Wood.
- Available in Satin Stainless Steel (630), Bronze Toned (613) & Black (BLK) finish.

Specification Data:

- UL 10C fire-rated, 3 hour single door (fail secure only).
- UL 10C fire-rated, 1-1/2 hour double door (fail secure only).
- CAN4-S104 (ULC-S104) fire door conformant.
- ANSI A250.13-2003 windstorm listed.
- ANSI-ASTM E330.
- Florida Building Code approved TAS 201, 202, 203.
- UL 1034, burglary-resistant listed and suitable for outdoor use.
- UL 294 (6th Edition) listed.
- ANSI/BHMA A156.31, Grade 1.
- California State Fire Marshall listed.
- NFPA-252 fire door conformant.
- ASTM-E152 fire door conformant.
- RoHS compliant.
- Patent pending.
- PoE friendly.

Electrical:
.24 Amps @ 12VDC continuous duty
.12 Amps @ 24VDC continuous duty

Fail Secure (Power-to-Unlock): Unlocked when energized. Locked when de-energized and during power failure.
Fail Safe (Power-to-Lock): Locked when energized. Unlocked when de-energized and during power failure.

Optional Features:

LM - Lock Monitor.
DLM - Dual Lock Monitor.
LMS - Lock Monitor and Strike Monitor.
DLMS - Dual lock monitors and Strike Monitor.
Interchangeable Faceplate Options - Monitor Switches may not work with all faceplate options. For 1500 Strike Faceplate Options see "Companion Items" above.

Specifications:

Literature:

Product Videos:

Product Videos:

Reviews

Reviews

There is no review yet for this item.
